How to charge a LiFePO4 batteries? That is one of the most common questions we get from our customers .If you are also looking to charge your RV battery safely and effectively, you are at the right place to find a solution. Our engineers will share with you how to better charge your RV battery.

Here are four safe and effective ways to charge:

Shore power

Generator

Motorhome or tow vehicle alternator

Solar energy

RV Lithium Battery Charger Types

When choosing the charger type to charge your RV lithium battery, you have various choices. Following chargers consider best to charge these batteries.

1. Converter Charger

Converter chargers, also termed AC chargers work by converting the alternating current into direct current. AC charger, just like a car battery charger, is a 120V to 12V converter. The converter charger cannot invert the charger as it only converts it.

Charging RV batteries with a converter charger is an automatic procedure. You can do it simply by plugging the RVs power cord into a 120V AC electrical outlet, and the charging process will start. It can convert the AC power to DC power to make charging more efficient and fast.

12-volt batteries can charge with an external battery charger. The external charger can decrease the charging time depending on its model either it decreases less time or more time. It is more suitable to charge a lithium RV batttery using a high amperage battery charger. It can prove faster and more effective to charge your RV battery.

2. Inverter Chargers

Inverter chargers act as both inverters and chargers. These chargers can effectively invert 12-volt DC power to 120-volt AC power. So, by using your RV battery bank, you can safely power electrical devices in your RV that require AC power. The inverter charger allows power to be switched between charging and discharging the battery. So one device can meet the usage needs of the RV.

3. Solar RV Battery Charge Controller

Solar ARV battery charge controller works by regulating the power that comes from the solar panels into the battery bank. The solar panel can locate on the RV roof. The overcharging of the battery can regulate by the regulator. Some RVs don't have a solar charging setup, so you require some initial setup to set a solar system such as wires, solar panel and solar charge controller( to regulate voltage). All essential solar panel accessories are available in a solar panel system kit. You can purchase it from a certified company.

4. Multi Battery Chargers

Whenever there is a need to use multiple batteries, all these batteries can install as a single large bank in parallel or series. In this case, the multi-battery chargers can use to charge the multiple batteries effectively. If the batteries connect to the various systems, you may need multiple chargers to charge multiple batteries.

Do I Have to Buy a Specific Charger for LiFePO4 Batteries?

No, there is no need to buy a special charger to charge your LiFePO4 batteries. If you have to charge a LiFePO4 battery with a voltage of 12V, you can use a charger with 14V to 14.6V.

The charger within this voltage range can effectively charge your LiFePO4 battery. But, it does not mean that you use a charger used to charge other lithium batteries.

Such chargers have a voltage higher than the voltage of the chargers designed to charge LiFePO4 batteries. So, it can affect your battery charging. The most recommended chargers for the LiFePO4 batteries consider LiFePO4 battery chargers, which effectively and safely charge the batteries.

What Chargers Does Lithium Battery Support?

The recommended charger for lithium batteries is less than ≤0.5C. Therefore for a 12V100Ah battery, it recommends using a charger ≤ 50A.

You should not exceed this charge rate as it can lead to a shortened battery cycle life. In an emergency, the battery can charge quicker if needed, but it needs to be within a reasonable temperature range. Most of our customers use 10A~20A chargers.

You use lithium batteries in numerous applications, so using the correct lithium battery and its charger is convenient. It would be best if you had a good idea of choosing the appropriate spec of charger that you are using for your lithium battery. To select the charger spec for your battery, you must have the following information.

• Battery Voltage
• Battery Amp Hour
• Time required to charge your lithium battery
• Charging Capacity of the Battery Management System

Can I Charge The 12v 100ah Battery With My Vehicle Alternator?

No. You can not charge a 12v 100ah battery with your vehicle alternative. You can charge it by using other chargers such as solar chargers, lithium battery chargers, or standard chargers.

What is The Best Type of RV Battery Charger?

Two main factors mainly decide the best types of RV battery chargers. It mainly depends on the battery type and the travel style. The best type of RV battery charger is multi-stage, programmable charging. The reason is that it can effectively charge all types of batteries and provides flexibility.

The Lithium Battery Charging Cycle Should Be Float or Not to Float?

Your lithium batteries do not need to float. After charging fully, you can store your battery, but you need to remember that your battery can lose a little charging with time, and you may need to top off when you bring them out from storage.

Storage can not damage your battery, but you should be careful running your appliance off the battery bank. Use a cutoff switch in the system and have a fixed voltage output converter. It suggests utilizing a disconnect switch to remove your battery from the circuit.

What Should Be The Proper Charging Voltage For The 12V Lithium Batteries?

You can choose a proper charging matching to the capacity of 12V lithium batteries. A lithium battery can charge at 1C, and a charger ranging between 13.8V to 14.6 V can use to charge any battery. It can not damage the battery. A 12.8V lithium battery has 13.4 full charge voltages. A universal charger can select the optimal voltage charge range, and during the charging of a lithium battery, it can shut off automatically when the entire battery can charge.

How Much Time is Required to Charge Lithium Batteries?

You must know how to charge your lithium batteries and how much time is required to charge a lithium battery. The even distribution of power supply and more cycles can be possible by purchasing lithium batteries, and they can charge faster than other batteries. It recommends selecting a charger that should be compatible with the chemistry of your battery.

Charging time can calculate by dividing the amp of the charger. A 100-amp hour LiFePO4 battery can take 2 hours to charge with a 50-amp charger. Charging time may depend on the used charger for your lithium batteries. For example, a 500AH battery needs 5 hours to charge with a 100-amp charger. If you exceed this charging rate, it can damage your battery life cycle and shorten its cycle.

More information of a RV LiFePO4 battery, please contact with MaxLi.
