Green Power Lithium Ion Battery Pack High Energy Conversion for Solar Chargers
The Green Power Lithium Ion Battery Pack is perfect for solar chargers. It has a high energy conversion rate, efficiently turning solar energy into usable power.
Equipped with an advanced BMS, it provides overcharging, over - discharge, overcurrent, and short - circuit protection, as well as temperature control. This safeguards the battery and prolongs its life.
The battery pack is durable, suitable for various environments. It's compact and lightweight, easy to integrate into different solar setups, be it for home, camping, or off - grid power systems. Truly an excellent choice for solar power utilization.
Technical Parameters:
|
Model
|
EA-12V-100Ah
|
EA-12V-200Ah
|
EA-24V-100Ah
|
|
Product parameter
|
Nominal voltage
|
12.8V
|
12.8V
|
25.6V
|
|
Nominal capacity
|
100AH
|
200AH
|
100AH |
|
Energy
|
1280WH
|
2560WH
|
2560WH
|
|
Cell assembly
|
3.2V100AH -4S1P
|
3.2V100AH -4S2P
|
3.2V100AH -8S1P
|
|
Dimension (mm)
|
330*173*221
|
522*238*222
|
522*238*222
|
|
Weight (KG)
|
11±0.5Kg
|
21±1Kg
|
21±1Kg
|
|
Cycle Life
|
>6000(25℃ , @0.5C 100%DOD)
|
|
Charge and discharge parameter
|
Charging voltage
|
14.4-14.6V
|
14.4-14.6V
|
28.8-29.2V
|
|
Discharge cut-off voltage
|
10V±0.5V
|
10V±0.5V
|
20V±0.5V
|
|
Maximum discharge current
|
100A
|
100A
|
100A
|
|
Maximum charging current
|
50A
|
100A
|
50A
|
|
Operating temperature
|
Discharge
|
20℃~55℃
|
|
Charging
|
0℃~55℃
|
|
Storage temperature
|
Within a month
|
-20℃~45℃
|
|
Within a year
|
0℃~35℃
|
|
Series-parallel quantity
|
Series connection
|
4
|
4
|
2
|
|
In parallel
|
4(Need to control the battery at the same voltage)
|
Packing and Shipping:
Our LiFePO4 lithium battery is meticulously packed to guarantee safe arrival. Each unit is securely enclosed in protective wrapping and placed in a durable box with cushioning materials to prevent any damage during transportation.
We collaborate with trusted shipping services to ensure fast and secure delivery. Every shipment includes tracking, allowing you to monitor your order in real time.
FAQ:
Q:What's the voltage of this battery pack?
It typically comes in 12V, 24V, and 48V options to meet diverse needs.
Q:Can it work in rainy weather?
Yes, its waterproof design allows it to function properly in wet conditions.
Q:How long does the battery last?
Under normal use, it can endure 6000 charge - discharge cycles.
Q:Is it easy to install?
Absolutely, with its user - friendly design and clear instructions, installation is a breeze.
